| Color | Black |
|---|
| Type | Intel ATX 12V 2.31 & EPS 12V 2.92 |
|---|
| Maximum Power | 500 W |
|---|
| Fans | 1 x 120mm Intelligent Cooling Fan |
|---|
| PFC | Active |
|---|
| Main Connector | 20+4Pin |
|---|
| +12V Rails | Single |
|---|
| PCI-Express Connector | 2 x 6+2-Pin |
|---|
| SATA Power Connector | 6 |
|---|
| SLI | SLI Ready |
|---|
| Haswell Support | Yes |
|---|
| CrossFire | CrossFire Ready |
|---|
| Modular | Hardlined |
|---|
| Power Good Signal | 100-500ms |
|---|
| Hold-up Time | 16.6ms min. |
|---|
| Efficiency | 80% Efficiency |
|---|
| Energy-Efficient | 80 PLUS Certified |
|---|
| Over Voltage Protection | Yes |
|---|
| Input Voltage | 100 - 240 V |
|---|
| Input Frequency Range | 50/60 Hz |
|---|
| Input Current | 8A |
|---|
| Output | +3.3V@20A, +5V@15A, +12V@35A, -12V@0.5A, +5VSB@2.5A |
|---|
| MTBF | >100,000 Hours |
|---|
| Approvals | CE, CB, TUV, UL, FCC |
|---|
| Max PSU Length | 140 mm |
|---|
| Connectors | 1 x 20+4-pin ATX
1 x 4+4-pin EPS
2 x 6+2-pin PCI-E
6 x SATA
3 x Peripheral
1 x Floppy |
|---|
